Nutech Overseas is a trusted TC fittings supplier in Saudi Arabia, delivering a wide range of Tri-Clamp / Dairy fittings designed for hygienic and sanitary applications. We supply across Riyadh, Jeddah, Dammam, Jubail, Yanbu, and Al Khobar, catering to industries that demand the highest levels of cleanliness and safety. All our products are manufactured in compliance with ASME BPE, ASTM, DIN, SMS, ISO, and 3A sanitary standards, ensuring superior performance, durability, and long service life.
Our TC fittings portfolio in Saudi Arabia includes: TC Ferrules, Clamps, End Caps, Gaskets, Reducers (Concentric & Eccentric), Bends, Elbows (45°/90°), U-Bends (180°), Tees, Crosses, Hose Barb Adapters, and Male/Female Threaded Adapters. These fittings are engineered from high-quality Stainless Steel 304, 316, and 316L, with a hygienic mirror polish finish that allows easy cleaning and sterilization. Sizes are available from ½” to 12”, making them suitable for both small-scale and large industrial systems.
Our TC fittings are widely used in food processing units, dairy plants, beverage industries, breweries, pharmaceuticals, cosmetics, and biotechnology facilities throughout Saudi Arabia. For example, Jubail and Yanbu utilize TC fittings in processing and chemical plants, while Riyadh and Jeddah see high demand from rapidly growing food, dairy, and pharma sectors. These fittings are designed for CIP (Clean-in-Place) and SIP (Sterilize-in-Place) operations, making them essential for industries where hygiene and contamination-free flow are critical.
Why Choose Nutech Overseas in Saudi Arabia?
- ISO Certified Manufacturer & Global Exporter
- Compliance with ASME BPE, ASTM, DIN, SMS, ISO & 3A standards
- Materials: Stainless Steel 304, 316, 316L with hygienic finish
- Sizes from ½” to 12” with high pressure resistance
- Supplies across all major Saudi cities – Riyadh, Jeddah, Dammam, Jubail, Yanbu, Al Khobar, Mecca, Medina, Taif, and Abha
- Export-ready packaging and on-time delivery
Nutech Overseas is committed to delivering the highest quality TC fittings in Saudi Arabia, backed by precision engineering and international certifications. For product inquiries, technical details, or quotations, please contact us at sales@nutechoverseas.com
Complete Specifications of TC Fittings
Below are the technical specifications for Tri-Clamp (TC) / Dairy fittings supplied by Nutech Overseas in Saudi Arabia. Specifications may be customized on request to meet project or industry requirements.
| Product Type | Standard(s) | Material Grades | Size Range | Typical Pressure Rating | Surface Finish (Internal / External) | Gasket Material | End Connection | Typical Application | Notes |
|---|---|---|---|---|---|---|---|---|---|
| TC Ferrules (Plain) | ASME BPE / DIN / SMS / 3A / ISO | SS 304, SS 316, SS 316L (optional higher alloys) | ½” – 12″ | Depends on size/design; typical working up to 10 bar (145 psi) | Internal Ra ≤ 0.8 µm (32 µin) / Mirror polish | EPDM, PTFE (Teflon), Silicone, NBR (on request) | Butt-weld / Weld-on / Butt clamp-ready ferrule | Hygienic pipe connections in food, dairy, pharma, beverage | Available in butt-weld and weld-neck variants |
| TC Clamps (Tri-Clamp) | ASME BPE / DIN / SMS / 3A | SS 304, SS 316, SS 316L | ½” – 12″ | Application dependent; secure clamp coupling for hygienic lines | External smooth finish; clamp surface polished | — (clamp holds gasket) | Tri-clamp clamp type (wing nut / bolt clamp) | Quick assembly/disassembly for CIP/SIP lines | Available in wing-nut and bolt clamp styles |
| TC Gaskets / Seals | ASME BPE / 3A / FDA compliant materials | EPDM, Silicone, PTFE (backed), NBR (food grade) | ½” – 12″ | Temperature & media dependent (verify with material) | — | EPDM / Silicone / PTFE / NBR | Fits Tri-Clamp ferrules | Sealing for hygienic and sterile process lines | FDA / EU food-contact grades available on request |
| Reducers (Concentric & Eccentric) | ASME BPE / DIN / SMS | SS 304, SS 316, SS 316L | ½” – 12″ (reducing combinations available) | Depends on sizes; typical hygienic system ratings | Internal Ra ≤ 0.8 µm / Mirror polish | — | Tri-Clamp ends / Butt-weld ferrule ends | Flow transitions in process piping, tanks, filters | Concentric for vertical lines; eccentric for horizontal drain lines |
| Elbows (45° / 90°) & Bends (U-Bend 180°) | ASME BPE / DIN / SMS | SS 304, SS 316, SS 316L | ½” – 12″ | Typical sanitary system working pressures | Internal Ra ≤ 0.8 µm / Mirror polish | — | Tri-Clamp / Butt-weld ferrule ends | Directional flow changes in CIP/SIP and process lines | Short-radius & long-radius options available |
| Tees (Equal & Reducing) | ASME BPE / DIN / SMS | SS 304, SS 316, SS 316L | ½” – 12″ | Application dependent | Internal Ra ≤ 0.8 µm / Mirror polish | — | Tri-Clamp / Butt-weld ferrule ends | Branching in process, sampling, CIP lines | Reducing tees for lateral size changes |
| Crosses | ASME BPE / DIN / SMS | SS 304, SS 316, SS 316L | ½” – 8″ | Application dependent | Internal Ra ≤ 0.8 µm / Mirror polish | — | Tri-Clamp / Butt-weld ferrule ends | Complex branch manifolds in hygienic systems | Use where four-way distribution required |
| End / Blank Caps | ASME BPE / DIN / SMS | SS 304, SS 316, SS 316L | ½” – 12″ | — | Internal Ra ≤ 0.8 µm / Mirror polish | — | Tri-Clamp / Butt-weld ferrule caps | Closing off lines during maintenance or commissioning | Available in removable and welded types |
| Hose Barb & Threaded Adapters (Male/Female) | ASME BPE / DIN / SMS (threads per DIN/ISO/BSP/NPT) | SS 304, SS 316, SS 316L | ½” – 2″ common sizes (custom sizes available) | Depends on connection type & gasket | Mirror polish external | EPDM / Silicone | Hose barb / BSP / NPT / ISO threads / Tri-Clamp ends | Flexible hose connections, sampling lines, small utilities | Specify thread type when ordering |
| Unions & Couplings | ASME BPE / DIN / SMS | SS 304, SS 316, SS 316L | ½” – 6″ | Application dependent | Mirror polish | EPDM / Silicone | Tri-Clamp / Threaded / Butt-weld | Removable connections for maintenance | Hygienic quick-release union options available |
Notes: 1) Actual pressure rating varies by size, material and specific fitting design — please confirm project requirements. 2) Surface finish and gasket selection can be customized (e.g., Ra 0.4 µm for critical pharma lines). 3) Certification & test reports (Material Test Certificate, PMI, Hydro test, Visual) available on request. For custom sizes, higher alloys (Inconel, Monel, Duplex / Super Duplex) or project-specific documentation required by Saudi clients (e.g., ARAMCO standards), contact sales@nutechoverseas.com.
